We often see the Event Bus architectural pattern in notification frameworks and Android development.  This approach provides us with a way to have a news feed mechanism across clients and processes. The Event Bus Pattern Defined There are three main players in this event bus pattern.  The players are the sources, the bus, and the listeners.  Within the bus, there are channels.  In this pattern, the listeners subscribe to a channel or channels.  Likewise, the sources post messages to one or more of these.  That allows sources to note something happened.  Likewise, any subscribers will see it.  Note that this is a one-way architecture.  Listeners will not communicate directly with sources.  However, you could have a return bus that listeners... Read more

This episode digs into the peer-to-peer software architecture pattern.  It is common among file-sharing and crypto networks.  Likewise, the pattern is not too complicated.  However, it is robust and secure as we have tightly defined communication paths.  We also have every node playing the role of both client and server. The Peer-To-Peer Pattern Defined The description of peer-to-peer is even less complex than client-server.  We have two nodes with a bi-directional link between them.  Each node can serve as a client or as a server.  Therefore, we also see this at times when we want to keep two machines synchronized for load balance and fail-over purposes.  The network can expand to any number of nodes.  However, each node connects to... Read more

The broker pattern may seem very similar to some others we have examined.  However, it is more about distributed systems than balancing traffic.  The pipe-filter and master-slave patterns provide single path processing.  This pattern sends the requests down different paths based on the request itself. The Broker Pattern Defined A broker pattern is a sort of tree structure.  We start with a client that makes a request to the broker.  The broker assesses that request and then sends it to a server that can handle the request.  Note that the selected server is not a candidate for load purposes as much as its services.  The broker queries servers (or server report when they register) for services provided.  This pattern allows... Read more

The pipe-filter architectural pattern is very common and used to process data.  It is flexible and scalable.  This pattern has existed in other areas.  However, it is the perfect solution for software problems that need steps or filters. The Pipe-Filter Pattern Defined Think of a start and an endpoint.  Data has to go from beginning to end, and work will be done on it along the way.  The work done is the filters, and we can place any number of filters along the journey.  Each one is stand-alone in a sense as it takes in data, does the work, and then spits it out on the other end.  We can change countless steps like this together as one might do... Read more
